extended.h
|
|
|
|
Copyright (c) 2020 Kevin Matz (kevin.matz@gmail.com)
|
|
|
|
Permission is hereby granted, free of charge, to any person obtaining a copy
|
|
of this software and associated documentation files (the "Software"), to deal
|
|
in the Software without restriction, including without limitation the rights
|
|
to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
|
|
copies of the Software, and to permit persons to whom the Software is
|
|
furnished to do so, subject to the following conditions:
|
|
|
|
The above copyright notice and this permission notice shall be included in all
|
|
copies or substantial portions of the Software.
|
|
|
|
THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
|
|
IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
|
|
FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
|
|
AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
|
|
LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
|
|
OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
|
|
SOFTWARE.
|
|
*/
|
|
#pragma once
|
|
|
|
#include "acn/pdu.h"
|
|
#include "uuid/uuid.h"
|
|
|
|
/**
|
|
* @brief both Discovery and Syncronization
|
|
*/
|
|
namespace sACN::EXTENDED {
|
|
|
|
/**
|
|
* @brief \cite sACN 6.3 E1.31 Synchronization Packet Framing Layer
|
|
*/
|
|
struct sync_header
|
|
: ACN::PDU::pdu_header
|
|
{
|
|
/// @brief \cite sACN 6.3.2 Synchronization Packet: Sequence Number
|
|
///
|
|
/// > Sources shall maintain a sequence for each universe they transmit.
|
|
/// > The sequence number for a universe shall be incremented by one for
|
|
/// > every packet sent on that universe. There is no implied relationship
|
|
/// > between the sequence number of an E1.31 Synchronization Packet and
|
|
/// > the sequence number of an E1.31 Data Packet on that same universe.
|
|
uint8_t sequence_number;
|
|
|
|
/// @brief \cite sACN 6.3.3 Synchronization Packet: Synchronization Address
|
|
///
|
|
/// > The Synchronization Address identifies the universe to which this
|
|
/// > synchronization packet is directed.
|
|
uint16_t sync_address;
|
|
|
|
/// @brief \cite sACN 6.3.4 Synchronization Packet: Reserved
|
|
///
|
|
/// > Octets 47-48 of the E1.31 Synchronization Packet are reserved for
|
|
/// future use. They shall be transmitted as 0 and ignored by receivers.
|
|
uint16_t reserved;
|
|
|
|
size_t streamSize() const override { return 5; }
|
|
void iStream(ACN::PDU::Stream) override;
|
|
void oStream(ACN::PDU::Stream) const override;
|
|
};
|
|
|
|
|
|
/**
|
|
* @brief \cite sACN 6.4 E1.31 Universe Discovery Packet Framing Layer
|
|
*/
|
|
struct discovery_header
|
|
: ACN::PDU::pdu_header
|
|
{
|
|
/// @brief \cite sACN 6.4.2 E1.31 Universe Discovery Packet: Source Name
|
|
///
|
|
/// > A user-assigned name provided by the source of the packet for use in
|
|
/// > displaying the identity of a source to a user. There is no mechanism,
|
|
/// > other than user configuration, to ensure uniqueness of this name. The
|
|
/// > source name shall be null-terminated. If the source component
|
|
/// > implements ACN discovery as defined in EPI 19 \cite epi19, then this
|
|
/// > name shall be the same as the UACN field specified in EPI 19
|
|
/// > \cite epi19. User-Assigned Component Names, as the title suggests,
|
|
/// > supply a single name for an entire component, so this Source Name
|
|
/// > field will exist for each unique CID, but may be the same across
|
|
/// > multiple universes sourced by the same component.
|
|
std::string source_name;
|
|
|
|
/// @brief \cite sACN 6.4.3 E1.31 Universe Discovery Packet: Reserved
|
|
///
|
|
/// Octets 108-111 of the E1.31 Universe Discovery Packet are reserved for
|
|
/// future use. They shall be transmitted as 0 and ignored by receivers.
|
|
uint32_t reserved;
|
|
|
|
size_t streamSize() const override { return 68; }
|
|
void iStream(ACN::PDU::Stream) override;
|
|
void oStream(ACN::PDU::Stream) const override;
|
|
};
|
|
|
|
|
|
/**
|
|
* @brief The EXTENDED::Pdu class
|
|
*/
|
|
class Pdu
|
|
: public ACN::PDU::Pdu
|
|
{
|
|
public:
|
|
Pdu();
|
|
void iStream(ACN::PDU::Stream) override;
|
|
};
|
|
|
|
|
|
/**
|
|
* @brief \cite sACN 1.6 Universe Discovery
|
|
*
|
|
* > This standard includes a Universe Discovery packet that sources must
|
|
* > provide in order to enumerate the universes upon which they are
|
|
* > transmitting. This allows other devices interested in network traffic to
|
|
* > monitor which universes are currently active, without the need to join
|
|
* > every multicast group to examine their individual transmissions.
|
|
*/
|
|
namespace DISCOVERY {
|
|
|
|
/**
|
|
* @brief Table 8-9: E1.31 Universe Discovery Packet Universe Discovery Layer
|
|
*/
|
|
struct discovery_list_header
|
|
: ACN::PDU::pdu_header
|
|
{
|
|
uint8_t page; //!< number of the current page
|
|
uint8_t last_page; //!< total pages
|
|
|
|
size_t streamSize() const override { return 2; }
|
|
void iStream(ACN::PDU::Stream) override;
|
|
void oStream(ACN::PDU::Stream) const override;
|
|
};
|
|
|
|
|
|
/**
|
|
* @brief The discoveredUniverse struct
|
|
*/
|
|
struct discoveredUniverse
|
|
{
|
|
UUID::uuid source; //!< CID of source
|
|
std::string description; //!< universe description
|
|
uint16_t universe; //!< universe number
|
|
|
|
friend bool operator== (const discoveredUniverse& a,
|
|
const discoveredUniverse& b);
|
|
friend bool operator< (const discoveredUniverse& a,
|
|
const discoveredUniverse& b);
|
|
};
|
|
|
|
|
|
/**
|
|
* @brief The discovery_list_data struct
|
|
*/
|
|
struct discovery_list_data
|
|
: ACN::PDU::pdu_data
|
|
{
|
|
std::vector<std::shared_ptr<discoveredUniverse>> found; //!< discovered universes
|
|
|
|
size_t streamSize() const override { return 2 * found.size(); }
|
|
void iStream(ACN::PDU::Stream) override;
|
|
void oStream(ACN::PDU::Stream) const override;
|
|
};
|
|
|
|
|
|
/**
|
|
* @brief \cite sACN 3.10 E1.31 Universe Discovery Packet
|
|
*
|
|
* > An E1.31 Universe Discovery Packet is a packet which contains a packed
|
|
* > list of the universes upon which a source is actively operating. It is
|
|
* > transmitted with the VECTOR_E131_EXTENDED_DISCOVERY vector.
|
|
*/
|
|
class Pdu
|
|
: public ACN::PDU::Pdu
|
|
{
|
|
public:
|
|
Pdu();
|
|
void iStream(ACN::PDU::Stream) override;
|
|
};
|
|
|
|
|
|
} // DISCOVERY
|
|
} // SACN::EXTENDED
|
|
|
|
namespace std
|
|
{
|
|
/**
|
|
* @brief The hash struct specialization for
|
|
* sACN::EXTENDED::DISCOVERY::discoveredUniverse
|
|
*/
|
|
template<>
|
|
struct hash<sACN::EXTENDED::DISCOVERY::discoveredUniverse>
|
|
{
|
|
/**
|
|
* @brief operator ()
|
|
* @param disc
|
|
* @return
|
|
*/
|
|
size_t operator()(sACN::EXTENDED::DISCOVERY::discoveredUniverse const& disc) const noexcept
|
|
{
|
|
size_t h1 = hash<string>{}(disc.description);
|
|
size_t h2 = hash<uint16_t>{}(disc.universe);
|
|
size_t h3 = hash<UUID::uuid>{}(disc.source);
|
|
size_t h = h1 ^ h2 ^ h3; // or use boost::hash_combine
|
|
return h;
|
|
}
|
|
};
|
|
} // namespace std
|
